P8AX25-F/MF
RF coaxial protector - 2 GHz
P8AX25-F/MF
Part Number:
60204
RF coaxial surge protector
2 GHz
190 W
Connectors : F
Low insertion loss
Removale GDT
DC-pass
Bi-directional protection
Installation Sheet
Contact Us
The P8AX series is based on gas discharge tube (GDT) and designed for RF line surge protection. Available for different power and with coaxial connectors, P8AX units could be provide in feedthrough mounting version and with various impedance.
Select another reference:
P8AX09-4310/MF
P8AX09-716/FF
P8AX09-716/MF
P8AX09-B/FF
P8AX09-B/MF
P8AX09-F/FF
P8AX09-F/MF
P8AX09-N/FF
P8AX09-N/MF
P8AX09-SMA/FF
P8AX09-SMA/MF
P8AX09-T/FF
P8AX09-T/MF
P8AX15-B/FF
P8AX15-B/MF
P8AX15-N/FF
P8AX15-N/MF
P8AX15-NWSMA/FF
P8AX15-SMA/FF
P8AX15-SMA/MF
P8AX25-4310/MF
P8AX25-716/FF
P8AX25-716/MF
P8AX25-B/FF
P8AX25-B/MF
P8AX25-F/FF
P8AX25-F/MF
P8AX25-N/FF
P8AX25-N/MF
P8AX25-NWSMA/FF
P8AX25-SMA/FF
P8AX25-SMA/MF
P8AX25-T/FF
P8AX25-T/MF
P8AX50-4310/MF
P8AX50-716/FF
P8AX50-716/MF
P8AX50-B/FF
P8AX50-B/MF
P8AX50-N/FF
P8AX50-N/MF
P8AX50-NWSMA/FF
P8AX50-T/FF
P8AX60-N/FF
P8AX80-716/FF
P8AX80-716/MF
Electrical Properties
Mechanical Properties
Norms
Schemas
Max. DC operating voltage
Uc
200 Vdc
Frequency range
f
DC-2 GHz
Insertion loss
< 0.5 dB
Return loss
> 19 dB
Impedance
75 ohms
VSWR
< 1.3:1
Max. load current
IL
10 A
Residual Current
Ipe
None
Max. discharge current
Imax
20 kA
Protection mode(s)
Common mode
Protection level
Up
< 800 V
Impulse current
Iimp
1 kA
Nominal discharge current
In
5 kA
Max Power
190 W
Typical let through energy
350 µJ
DC Pass
ZERTZAERTZERTZER
True
Insulation resistance
IR
≥10 GOhms
Technology
Gas discharge tube
Connection to Network
Connector F Male/Female
Mounting
Feedthrough
Housing material
Brass/Surface plating: Cu Zn Sn
Operating temperature
Tu
-40/+85°C
Protection rating
IP66
Outdoor application
Yes
Failsafe mode
Short-circuit
Disconnection indicator
Transmission interrupt
Spare module(s)
BBHF-250V
Dimensions
See diagram
Contacts
Bronze/Surface Au-Ag
Standards compliance
IEC 61643-21 / EN 61643-21 / UL497C / UL497E
RohS compliance
Yes
