Gas tube technology
P8AX09-6G-N/FF/HE
Coaxial surge protector DC-7 GHz
P8AX09-6G-N/FF/HE
Part Number
680114
RF coaxial surge protector
Harsh environment (HE)
DC-7 GHz
70 W
Connectors : N
Low insertion loss
Removale GDT
DC-pass
Bi-directional protection
Datasheet
Installation Sheet
Tender specifications
Contact Us
The P8AX series is based on gas discharge tube (GDT) and designed for RF line surge protection. Available for different power and with coaxial connectors, P8AX units could be provide in feedthrough mounting version and with various impedance.
Select another reference:
P8AX09-6G-N/FF/HE
P8AX09-N/FF/HE
P8AX15-NWSMA/FF
P8AX25-B/FF
P8AX25-B/MF
P8AX25-F/FF
P8AX25-F/MF
P8AX25-NWSMA/FF
P8AX50-NWSMA/FF
P8AX60-N/FF
Electrical Properties
Mechanical Properties
Norms
Schemas
Max. DC operating voltage
Uc
120 Vdc
Frequency range
f
DC-7 GHz
Insertion loss
< 0.2 dB
Return loss
> 19 dB
Impedance
50 ohms
VSWR
<1.25:1
Max. load current
@25°C
IL
10 A
Operating current
Continious current at Uc
Ic
None
Max. discharge current
max. withstand @ 8/20 µs by pole
Imax
20 kA
Protection mode(s)
Common mode
Protection level
@ In (8/20µs)
Up
< 1100 V
Impulse current
2 x 10/350µs Test - D1 Category
Iimp
1 kA
Nominal discharge current
C2 Category
In
5 kA
Max Power
70 W
Typical let through energy
(50 ohms) input 4kV 1.2/50μs - 2kA 8/20μs
2.2 mJ
DC Pass
Yes
Insulation resistance
IR
≥10 GOhms
Technology
Gas discharge tube
Connection to Network
Connector N Female/Female
Mounting
Feedthrough
Housing material
Brass/Surface plating: Sn Ni
Operating temperature
Tu
-40/+85°C
Protection rating
IP66
Outdoor application
Yes
Failsafe mode
Short-circuit
Disconnection indicator
Transmission interrupt
Spare module(s)
1 x BA HF
Dimensions
See diagram
Contacts
Bronze/Surface Gold or Silver
Weight
0.165 kg
Standards compliance
IEC 61643-21 / EN 61643-21 / UL497E
RohS compliance
Yes
×
Description:
Coaxial surge protector DC-7 GHz
Standards compliance:
IEC 61643-21 / EN 61643-21 / UL497E
Technology:
Gas discharge tube
Max. DC operating voltage:
120 Vdc
Frequency range:
DC-7 GHz
Max. discharge current :
20 kA
Protection level :
< 1100 V
CITEL
Reference:
P8AX09-6G-N/FF/HE
Part Number:
680114
Or equivalent
