Surge protector for LED lighting system Class 2

MLPM2-230L-R
Part Number 842211
MLPM2-230L-R
  • Type 2 (or 3) surge protectors for LED
  • For single phase 230 V network
  • Class 2
  • Very compact
  • Plate mounting
  • Spring terminal connection
  • Status indicator
  • End of life : AC Disconnection
  • EN 61643-11, IEC 61643-11 certified
Contact Us
The MLPM range is a series of AC surge protectors dedicated to LED lighting system. The MLPM are very compact to be integrated into luminaires by spring connexion terminal. This range is equipped with a mechanical disconnect indicator exclusive to CITEL.
Select another reference:
SPD type
IEC

2+3
Network

220-240 V Single-phase
AC system

TT-TN
Max. AC operating voltage
Uc

275 Vac
Max. load current @25°C
 IL

10 A
Temporary Over Voltage (TOV) Characteristics - 5 sec.
Without disconnection
 UT

335 Vac withstand
Temporary Over Voltage (TOV) Characteristics - 120 mn
Without disconnection or with safety disconnection
 UT

440 Vac disconnection
Residual Current
Leakage current to Ground
 Ipe

None
Nominal discharge current
15 x 8/20 µs impulses
 In

5 kA
Max. discharge current
max. withstand @ 8/20 µs by pole
 Imax

10 kA
Withstand on Combination waveform IEC 61643-11
Class III test: 1.2/50µs - 8/20µs
 Uoc

12 kV
Protection mode(s)

Differential Mode
Protection level L/N
@ In (8/20µs)
 Up L/N

1.2 kV
Admissible short-circuit current
 Isccr

10 000 A
Technology

MOV+GDT
Connection to Network

2 spring terminals opposite side in/out - wire 1.5mm² max.
Mounting

On plate
Housing material

Thermoplastic UL94 V-0
Operating temperature
 Tu

-40/+85°C
Protection rating

IP20
Failsafe mode

Disconnection and AC line cut-off
Disconnection indicator

1 mechanical indicator
Operating indicator

Mechanical
Dimensions

See diagram
Weight

0.026 kg
Standards compliance

EN 61643-11 / IEC 61643-11
Certification

KEMA / ENEC05
Thermal disconnector

Internal
Installation ground fault breaker

Type 'S' or delayed
