Surge and Electrostactic protector for Class II LED lighting system

MLPC2-230L-V/ESP2
Part Number: 832227
MLPC2-230L-V/ESP2
  • Type 2 (or 3) Surge & Electrostatic protectors
  • For Class II Led lighting
  • Improved coordination with internal MOV
  • Electrostatic protection included
  • Comply class II safety rules
  • Very compact
  • Plate mounting
  • Screw terminal connection
  • Status indicator
  • End of life AC Disconnection
  • IEC 61643-11 and EN 61643-11 compliance


Select another reference:

SPD type
2+3
Network
220-240 V Single-phase
AC system
TT-TN
Max. AC operating voltage
Uc 320 Vac
Max. load current
IL 5 A
Temporary Over Voltage (TOV) Charasteristics - 5 sec.
Without disconnection
UT 335 Vac withstand
Temporary Over Voltage (TOV) Charasteristics - 120 mn
Without disconnection or with safety disconnection
UT 440 Vac disconnection
Residual Current
Leakage current to Ground
Ipe None
Nominal discharge current
15 x 8/20 µs impulses
In 5 kA
Max. discharge current
max. withstand @ 8/20 µs by pole
Imax 10 kA
Total Maximum discharge current
max. total withstand @ 8/20 µs
Imax Total 20 kA
Withstand on Combination waveform IEC 61643-11
Class III test: 1.2/50µs - 8/20µs
Uoc 10 kV
Withstand on overvoltages IEEE C62.41.1
10 kV / 10 kA
Protection level
@ In (8/20µs)
Up 1.5 kV
Admissible short-circuit current
Isccr 10 000 A
Electrostatic protection level
Uesp > 0.5 kV
Electrostatic protection mode
N/Functional Earth
Connection to Network
2 screw terminals opposite side in/out - wire 2.5mm² max.
Mounting
On plate
Housing material
Thermoplastic UL94 V-0
Operating temperature
Tu -40/+85°C
Protection rating
IP20
Failsafe mode
Disconnection and AC line cut-off
Disconnection indicator
LED green OFF and AC network cut-off
Voltage/operating indicator
Green Led ON
Dimensions
See diagram
Weight
0.042 kg
Standards compliance
EN 61643-11 / IEC 61643-11
Certification
Thermal disconnector
Internal
Installation ground fault breaker
Type 'S' or delayed
