Surge and Electrostactic protector for Class II LED lighting system

Part Number: 832217
  • Type 2 (or 3) Surge & Electrostatic protectors
  • For Class II Led lighting
  • Improved coordination with internal MOV
  • Electrostatic protection included
  • Comply class II safety rules
  • Very compact
  • Plate mounting
  • Spring terminal connection
  • Status indicator
  • End of life AC Disconnection
  • IEC 61643-11 and EN 61643-11 compliance

Select another reference:

SPD type 2+3
Isolation classe II
Network 220-240 V Single-phase
AC system TT-TN
Max. AC operating voltage Uc 320 Vac
Max. load current IL 5 A
Temporary Over Voltage (TOV) Charasteristics - 5 sec. UT 335 Vac withstand
Temporary Over Voltage (TOV) Charasteristics - 120 mn UT 440 Vac disconnection
Residual Current Ipe None
Nominal discharge current In 5 kA
Max. discharge current Imax 10 kA
Total Maximum discharge current Imax Total 20 kA
Withstand on Combination waveform IEC 61643-11 Uoc 10 kV
Withstand on overvoltages IEEE C62.41.1 10 kV / 10 kA
Protection level Up 1.5 kV
Admissible short-circuit current Isccr 10 000 A
Electrostatic protection level Uesp > 0.5 kV
Electrostatic protection mode N/Functional Earth
Connection to Network 2 screw terminals opposite side in/out - wire 2.5mm² max.
Mounting On plate
Housing material Thermoplastic UL94 V-0
Operating temperature Tu -40/+85°C
Protection rating IP20
Failsafe mode Disconnection and AC line cut-off
Disconnection indicator LED green OFF and AC network cut-off
Voltage/operating indicator Green Led ON
Dimensions See diagram
Weight 0.035 kg
Standards compliance EN 61643-11 / IEC 61643-11
Certification UL / EAC / TUV
Thermal disconnector Internal
Installation ground fault breaker Type 'S' or delayed
