19'' patch panel surge protector for high-speed network

RAK16-E-C6
Part Number 6254
RAK16-E-C6
  • 19'' patch panel surge protector for CAT6
  • 16 ports
  • In/Out front : RJ45
  • Maintenance possible per port
  • Secondary protection
  • UL497B

The RAK series of rack mount and wall mount standoff protectors will ensure the reliable operation of networked equipment connected to 10/100/1000BaseT Ethernet, Cat5, Cat6, PoE and most other communication interfaces.

Select another reference:

Network
100/1000/10G BaseT, RS422, RS485, RS423, Ethernet
Nominal line voltage
Un 5 Vdc
Max. DC operating voltage
Uc 7.5 Vdc
Max. frequency
f max. 250 MHz
Max. data rate
10 Gbps
Insertion loss
< 1 dB
Max. load current
@25°C
IL 750 mA
Protection level
Following the test category C3 (IEC61643-21) - Line/Line
Up 20 V
Max. capacitance
C < 8 pF
Discharge current
at 10/1000µs impulse current
100 A
Line/Line Nominal discharge current
C2 Category
In L/L 500 A
Nominal Discharge Current, X-C (Line/Earth)
8/20µs Test x 10 - C2 Category
In L/PE 500 A
Technology
Diode écrêtage
SPD configuration
16 ports of 8 wires
Connection to Network
RJ45 Female intput/output
Format
Rack 19''
Mounting
Baie 19''
Housing material
Aluminium
Operating temperature
Tu -40/+85°C
Protection rating
IP20
Outdoor application
No
Failsafe mode
Short-circuit
Disconnection indicator
Transmission interrupt
Spare module(s)
1-port removable circuit
Remote signaling of disconnection
No
Pinout
(1-2)(3-6)(4-5)(7-8)
Dimensions
See diagram
Weight
0.62 kg
Standards compliance
IEC 61643-21 / EN 61643-21 / UL497B / IEEE 802-3an
