Screw terminal for 'V' connection

Part Number: 400132
DDT16
DDT16
DDT16
DDT16
DDT16
  • 'V' connection screw terminal for SPD
  • Improved connection for better efficiency
  • 2 x 35 mm² wire connection
  • Adapted to DAC/DDC surge protectors
The DDT16 is a terminal adapter that transforms a screw terminal into a double terminal to connect an incoming and an outgoing cable, with a maximum section of 35 mm² per conductor. This product is intended for CITEL's DAC/DDC ranges.
Select another reference:
DDT16

Max. AC operating voltage
 Uc

1000 Vac
Max. DC operating voltage
 Uc

1500 Vdc
Max. load current @25°C
 IL

100 A

Mounting

On DAC/DDC range terminal
Housing material

Polycarbonate UL94 V-0
Ingress Protection rating

IP00
Dimensions

See diagram
Contacts

Brass
Mini-max. cross section

2.5 - 25 mm² (12-4 AWG), solid, stranded & flexible
Torque

2-2.2 Nm (18-22 lb-in)

Standards compliance

UL1059
