Support for E280 plug-in modules
Part Number: 71480
MMP
- Connector strip for 2 x E280
- Max. number of pairs : 4
This connector strip MMP, designed to receive 2x E280 surge protectors (4 pairs), is installed on MDF in mechanical adaptation with the other connector strips.
Earthing is automatically performed through the pin in contact with the metallic frame
Select another reference:
MMP
Datasheet|
Network
|
Low current |
|
|
Max. frequency
|
f max. |
|
|
Insertion loss
|
< 1 dB |
|
|
Max. load current @25°C
|
IL | 5 A |
|
Max. discharge current
max. withstand @ 8/20 µs by pole
|
Imax | 10 kA |
|
Nominal discharge current
C2 Category
|
In | 5 kA |
|
Impulse current
2 x 10/350µs Test - D1 Category
|
Iimp | 2.5 kA |
|
SPD configuration
|
4 pairs |
|
|
Connection to Network
|
Earth pin |
|
|
Format
|
Strip |
|
|
Mounting
|
MDF |
|
|
Housing material
|
Thermoplastic UL94 V-0 |
|
|
Operating temperature
|
Tu | -40/+85°C |
|
Protection rating
|
IP20 |
|
|
Outdoor application
|
No |
|
|
Connection
|
connector CAD |
|
|
Max. number of E280s
|
2 | |
|
Max. number of pairs
|
4 | |
|
Dimensions
|
See diagram |
