Coaxial surge protector for video transmission networks

CXC06-B/MF
Part Number 630134
CXC06-B/MF
  • Coaxial surge protector
  • Multiples connectors
  • Low insertion loss
  • Easy installation
Contact Us
CXC surge protectors are designed to protect sensitive equipment, connected to coaxial lines as computer networks, video-transmission, against transient surge voltages and disturbances created by lightning. The scheme of CXC, gas tube/clamping diode hybrid association allowing heavy discharge current and low residual voltage.*
Select another reference:
Network

coaxial DC-70 MHz
Nominal line voltage
 Un

6 V
Max. DC operating voltage
 Uc

8 Vdc
Max. frequency
 f max.

DC-70 MHz
Insertion loss

≤0.6 dB
Return loss

≥20 dB
Impedance

50 ohms
VSWR

< 1.5:1
Max. load current @25°C
 IL

0.5 A
Operating current
Continious current at Uc
 Ic

None
Max. discharge current
max. withstand @ 8/20 µs by pole
 Imax

10 kA
Protection level
@ In (8/20 µs)
 Up L/L

25V / 600V
Impulse current
2 x 10/350µs Test - D1 Category
 Iimp

2.5 kA / 10 kA
Nominal discharge current
C2 Category
 In

5 kA
Max Power

6 W
DC Pass

Yes
Technology

GDT + R + Diode
Connection to Network

Connector BNC Male/Female
Format

Metallic box
Mounting

On cable
Housing material

Brass
Operating temperature
 Tu

-40/+85°C
Protection rating

IP20
Outdoor application

No
Failsafe mode

Short-circuit - transmision cut-off - fault mode 2
Disconnection indicator

Transmission interrupt
Dimensions

See diagram
Weight

0.064 kg
Standards compliance

IEC 61643-21 / EN 61643-21 / UL497E
RohS compliance

Yes
