DC Fuse for Energy Storage System (ESS) Application with its base and a remote signal
Part Number: 64137
SFD50S-10-1500DC
- Specific Fuses (SPD Fusing Disconnectors) for short circuit protection of Type 2 DC surge protectors
- For Energy Storage application
- To associate with the CITEL SPD range: DDC50-21Y
- Status and remote signaling
- Supplied with mounting base
- IEC 60269-7 compliance
Select another reference:
SFD50S-10-1500DC
Certificates
Datasheet
|
Max. DC operating voltage
|
Uc | 1500 Vdc |
|
Nominal discharge current
15 x 8/20 µs impulses
|
In | 20 kA |
|
Equivalent rated AC current
|
50 A gBat |
|
|
Breaking capacity
|
100 000 A |
|
|
Power dissipation
|
14 W / 6 W (0.7xln) |
|
Fuse configuration
|
1-pole |
|
|
Format
|
NH1XL |
|
|
Mounting
|
On CITEL base: BSFD50-10 PN:39602 (included) |
|
|
Disconnection indicator
|
Top fuse status indicator |
|
|
Remote signaling of disconnection
|
Output on changeover contact |
|
|
Dimensions
|
See diagram |
|
Standards compliance
|
IEC 60269-7 |
|
|
Certification
|
||
|
RohS compliance
|
Yes |
