Lightning Monitoring System for Wind Turbines

LMS-W
Part Number: 790623
LMS-W
  • Smart lightning monitoring system for wind turbines.
  • 1 monitor + 3 sensors for the blades
  • Monitoring, record the data for surge current, time of lightning strike, etc.
  • Transmit the data by means of RS485.
  • IEC 61400-24 and IEC 62561-6 compliant

The LMS-W is a smart lightning monitoring system developed by CITEL for wind turbines. LMS-W is mainly used for surge current measurement when lightning strike on each of three blades, the lightning surges can be detected by corresponding sensors and then data can be transmitted to monitoring device of the upper computer through RS485. By means of smart and precise monitoring of LMS-W, necessary and timely maintenance for blades can be ensured when unexpected lightning current happens, and the possibility of downtimes of the operation system caused by fatal error can be reduced.

Select another reference:

Minimum current sensibility Itc 10 kA
Max. admissible impulse current Imcw 200 kA
Life time 10 years
Power 24 Vdc
Mounting On plate
Operating temperature Tu -40°C bis + 70°C
Protection rating IP67
Dimensions 66 x 55 x 47 mm
Weight 1.600 kg
Standards compliance IEC 61400-24, IEC 62561-6
